GEYA GYHC-25A Modular Power Contactor (2NO, 230V)

The GEYA GYHC-25A Modular Power Contactor is engineered for remote control and switching of electrical loads in home, commercial, and industrial automation setups. Thanks to its standard modular form-factor, the device easily integrates into distribution boards alongside other circuit breakers. Equipped with two normally open contacts (2NO) and a 230V operating coil, it is perfectly suited for managing lighting systems, heating elements, water pumps, ventilation units, as well as for Automatic Transfer Switch (ATS) systems and Smart Home applications. The unit provides highly reliable connections, quiet operation, and exceptional durability.

Features:

• Space-saving modular housing with a width of just 18mm (1 DIN module)

• Direct snapshot installation on standard 35mm DIN-rails

• Front-panel visual status indicator for quick contact state verification

• High mechanical and electrical wear-resistance of the contact system

• Ultra-quiet operations and optimized low power consumption of the coil

• Enhanced safety design with touch-proof screw terminals

Specifications:

• Device Type: Modular AC Power Contactor

• Model: GYHC-25

• Pole Configuration / Contacts: 2 Poles / 2NO (Normally Open)

• Rated Operational Current (AC-7a): 25A (for resistive loads)

• Rated Operational Current (AC-7b): 9A (for inductive motor loads)

• Control Coil Voltage: AC 230V (50/60 Hz)

• Rated Insulation Voltage (Ui): 500V

• Rated Operational Voltage (Ue): 250V

• Standards & Compliance: EN 61095, IEC 61095, CE

Package Includes:

• GEYA GYHC-25A 2NO Modular Contactor

• Original Packaging
