Powerful universal converter based on LTC3780 XR-131

The powerful universal converter based on LTC3780 is designed for efficient step-up and step-down voltage conversion with adjustable output parameters. This module enables the conversion of a wide range of input voltages into stabilized output voltage, ensuring high efficiency and reliability. The LTC3780 is ideal for use in power systems that require adjustable output voltage to power various devices.

Advantages:

• Wide Input Voltage Range: Supports input voltage from 5V to 32V.
• Adjustable Output Voltage: Allows setting output voltage in the range from 1V to 30V.
• High Efficiency: Up to 98% efficiency ensures minimal energy loss.
• Versatility: Suitable for both boosting and bucking voltage, making it perfect for various applications.
• Reliability: Built-in protection features against overheating, overloading, and short circuits.

Key Specifications:

• Type: Buck-Boost Voltage Converter
• Model: LTC3780
• Input Voltage: 5V - 32V DC
• Output Voltage: 1V - 30V DC (adjustable)
• Maximum Output Current: 10A
• Efficiency: Up to 98%
• Adjustment: Potentiometers for adjusting output voltage and current
• Protection Features: Overheating, overloading, short circuit protection
• Dimensions: 60 mm x 60 mm x 22 mm
• Weight: 35 g
• Indicators: LED status indicator

Applications:

Ideal for:

• Use in power systems for voltage stabilization
• Charging batteries and powering portable devices
• Automotive and solar systems
• Prototyping and developing adjustable power supplies
• Electronic DIY projects

Features:

• Flexible Application: Can be used as both a step-up and step-down converter.
• Easy Integration: Easily integrates into various circuits and devices due to its compact size.
• High Reliability: Built-in protective functions ensure safe operation.

The powerful universal converter based on LTC3780 provides a reliable solution for obtaining regulated and adjustable power in various electronic systems.
